Термопомпа HYUNDAI Split With Integrated Tank HYHA-V12W/D2N8 / HYHB-A160/240CD30GN8
€0,00 EUR
| ОБЕМ НА БОЙЛЕРА | 240 литра (неръждаема стомана) | ||
|---|---|---|---|
| |
COP | 3 | |
| COP | 3,73 | ||
| COP | 2,24 | ||
| Heating (A7/W35) | Capacity | kW | 12.10 |
| Rated input | kW | 2.44 | |
| COP | 4.95 | ||
| Heating (A7/W45) | Heating | kW | 12.30 |
| P electric consumption | kW | 3.24 | |
| COP | 3.80 | ||
| Cooling (A35/W18) | Capacity | kW | 12.00 |
| Rated Input | kW | 3.00 | |
| EER | 4.00 | ||
| Cooling (A35/W7) | Capacity | kW | 11.60 |
| Rated Input | kW | 4.22 | |
| EER | 2.75 | ||
| Seasonal space heating energy efficiency class | LWT 35C | A+++ | |
| cf EN14511/2018; EN14825/2018; EU No:811/2013 | 4,81 | ||
| LWT 55C | A++ | ||
| 3,45 | |||
| INDOOR UNIT | HYHB-A160/240CD30GN8 | ||
| Power supply | V, Ph, Hz | 220-240, 1, 50 | |
| Rated input | W | 3 095 | |
| DHW tank | Volume | L | 240 |
| Max DHW temp | °С | 60 | |
| Heat exhanger | plate | ||
| Circulation pump | Type | DC Inverter type | |
| Max head | mCA | 9 | |
| Hydraulic | Heating connections | inch | R1" |
| DHW connections | inch | R3/4" | |
| back-up E-heater | kW | 3 | |
| Outside temp range | Cooling | °С | 5~25 |
| Heating | °С | 25~65 | |
| DHW | °С | 30~60 | |
| Sound pressure | dB(A) | 42 | |
| Net weight | kg | 159 | |
| Dimmensions | W x D x H | mm | 600x600x1943 |
| OUTDOOR UNIT | HYHA-V12W/D2N8 | ||
| Power supply | V, Ph, Hz | 220-240, 1, 50 | |
| Refrigerant | Type (GWP) | R32 (675) | |
| Charged volume | kg | 1.84 | |
| Refrigerant to be added | g/m | 38 | |
| Refrigerant piping | Liquid side | mm | 9,52 |
| connections | Gas side | mm | 15,9 |
| Mx piping length | m | 30 | |
| Max difference in height | m | 20 | |
| Compressor | BLDC Inverter - MITSUBISHI ELECTRIC | ||
| Sound power | dB(A) | 64 | |
| Drain connection | DN32 | ||
| Outside temp range | Cooling | °С | -5~43 |
| Heating | °С | -25~35 | |
| DHW | °С | -25~43 | |
| Net weight | kg | 100 | |
| Dimensions | W x D x H | mm | 1118x865x523 |
